Thyristor Modules

• Application
• Rectifiers, Power Controllers, Inverters

• Capacity
• Various, up to 100A

• Color
• Black & Silver

• Components
• Power Thyristor, Aluminum baseplate, Encapsulated Cover

• Current Rating
• Up to 100A

• Dimension (L*W*H)
• 106mm x 42mm x 35mm

• Features
• Compact, High reliability, Low leakage current, Easy mounting

• Frequency
• 50Hz / 60Hz

• Function
• Used for switching and controlling high voltage and current circuits

• IP Rating
• IP20

• Input
• Gate Trigger Current

• Interface
• Screw Terminal

• Operating Temperature
• -40C to +125C

• Output
• Controlled AC or DC Output

• Power Source
• External Power Line

• Power Supply
• AC/DC

• Product Type
• Thyristor Module

• Rated Voltage
• 1600V

• Response Time
• Fast switching

• Size
• Standard

• Supply Voltage
• 1200V - 1600V

• Thermal Conductivity
• Good (With aluminum base)

• Thickness
• Approx 35mm

• Usage
• Industrial Power Control

• Weight
• Approx 350g

• Application
• Rectifiers, Phase Controls, Power Supply Units

• Color
• Black / Grey

• Current Rating
• 106 A

• Dimension (L*W*H)
• 106mm x 55mm x 30mm (Approx.)

• Function
• Dual Thyristor Power Module

• Input
• Control Signal

• Operating Temperature
• -40C to +125C

• Output
• High Power AC/DC

• Power Source
• Electric

• Product Type
• Phase Control Thyristor Module

• Rated Current
• 100 Ampere (amp)

• Rated Voltage
• 1600 Volt (V)

• Size
• Industry Standard Module

• Supply Voltage
• Up to 1600 V

• Usage
• Power Electronics Applications

• Weight
• Around 330 g

• Application
• Power Switching, Motor Drives, Power Control

• Capacity
• 162 A

• Color
• Black

• Components
• 2 Thyristors (SCRs) in dual configuration

• Current Rating
• 162 A

• Dimension (L*W*H)
• 106 x 45 x 30 mm (approx.)

• Features
• Isolated Base, Compact Encapsulation, High Surge Current Capability, Maintenance-free

• Frequency
• 50/60 Hz

• Function
• Dual Thyristor Module

• IP Rating
• IP00

• Input
• AC

• Interface
• Stud Terminals for Power, Faston Tabs for Gate connections

• Operating Temperature
• -40C to +125C

• Output
• Controlled Rectified

• Power Source
• Electric

• Power Supply
• Electric

• Product Type
• Phase Control Thyristor Module

• Rated Voltage
• 1600 V

• Response Time
• Fast switching

• Size
• Industry Standard Module

• Supply Voltage
• 1600V

• Thermal Conductivity
• High, with baseplate for heat sink mounting

• Thickness
• Standard Housing

• Usage
• Power Electronics, Three Phase Rectifiers, AC/DC Motor Drives

• Weight
• 590 g approx.
