Power Diode

• Application
• Motor drives, power supplies, inverters, welding equipment

• Capacity
• High current capacity

• Color
• Black body with metallic connectors

• Components
• Silicon diode(s), module case, connectors

• Current Rating
• 50A

• Dimension (L*W*H)
• 100 x 60 x 38 mm

• Features
• Compact design, high efficiency, easy mounting, high surge current capability

• Frequency
• 50/60 Hz compatible

• Function
• Rectification and power conversion

• IP Rating
• IP20

• Input
• AC/DC

• Interface
• Screw terminals

• Operating Temperature
• -40C to +125C

• Output
• DC

• Power Source
• Electrical mains

• Power Supply
• AC/DC

• Product Type
• Diode Module

• Rated Voltage
• 1200V

• Response Time
• Fast recovery

• Size
• Standard module size

• Supply Voltage
• Up to 1200V

• Thermal Conductivity
• High, with heat dissipation design

• Thickness
• 38 mm

• Usage
• Industrial and general electronic applications

• Weight
• Approx. 350 g

• Application
• Industrial power electronics, power conversion, UPS, motor drives

• Capacity
• 20A Average Forward Current

• Color
• Black

• Components
• Silicon Semiconductor

• Current Rating
• 20A (Average Forward)

• Dimension (L*W*H)
• Approx. 9.5mm x 5.5mm x 5.5mm

• Features
• Low reverse recovery time, high surge capacity, high current capability

• Frequency
• High Frequency Applications

• Function
• High-speed switching, rectification

• IP Rating
• Not Rated

• Input
• DC

• Interface
• Lead Type

• Operating Temperature
• -55C to +150C

• Output
• DC

• Power Source
• External Circuit

• Product Type
• Fast Recovery Diode

• Rated Voltage
• 400V

• Response Time
• Fast Recovery Time

• Size
• DO-201AD

• Supply Voltage
• Up to 400V

• Thermal Conductivity
• High (Efficient Heat Dissipation)

• Thickness
• Standard Package Thickness

• Usage
• Rectification in power supplies, freewheeling diodes, snubber circuits

• Weight
• Approx. 2 g
